100G QSFP28

100G ZR4 100GBASE 80km Transceiver

Supports 103.125Gb/s aggregate bit rates , Lane bit rate 25.78 Gb/s 100GE
Up to 80km transmission with KR4-FEC , LAN WDM EML laser and PIN receiver with SOA
Support Multi-Pin function with IntL/RxLOSL and LPMode/TxDIS
QSFP28 MSA package with duplex LC connector
Product description: 100GBASE-ZR4 is designed for 80km optical communication applications. This module contains 4-lane optical transmitter, 4-lane optical receiver and module management block including 2 wire serial inter
INQUIRY

Supports 103.125Gb/s aggregate bit rates , Lane bit rate 25.78 Gb/s 100GE

Up to 80km transmission with KR4-FEC , LAN WDM EML laser and PIN receiver with SOA

Support Multi-Pin function with IntL/RxLOSL and LPMode/TxDIS

High speed I/O electrical interface (CAUI-4) , I2C interface with integrated DDM

QSFP28 MSA package with duplex LC connector

Single +3.3V power supply

100GBASE-ZR4 is designed for 80km optical communication applications. This module contains 4-lane optical transmitter, 4-lane optical receiver and module management block including 2 wire serial inter-face. The optical signals are multiplexed to a single-mode fiber through an industry standard LC connector. A block diagram is shown in Figure.
